YUBRIGHT PCB PRODUCTION CAPABILITY
Panel size(max) 510*450mm
Thickness 0.6~2.5mm
Thickness tolerance ±0.1mm
Width of fine line 0.1mm
Width bet fine line 0.1mm
Tiny hole diameter 0.25mm
Layers of PCB 2/4/6/8/10 layers
SMD pitch(min) 0.4mm
SMD size(min) 0.2mm
Circuit alignment tolerance 0.075mm
Layers alignment tolerance 0.075mm
S/M tolerance 0.075mm
G/F planting 3~50 u
Warpage&twist 1%
E-test voltage 150v~250v
YUBRIGHT PCB MAIN EQUIPMENTS
|
1 |
PTH Line |
1 |
|
2 |
Plating Line |
3 |
|
3 |
Brusher |
6 |
|
4 |
5kw Exposure Machine |
6 |
|
5 |
7kw Exposure Machine |
5 |
|
6 |
Dry Film Developer |
2 |
|
7 |
LPI Developer |
2 |
|
8 |
Film Developer |
3 |
|
9 |
Auto Printer |
2 |
|
10 |
Semi-Auto Printer |
12 |
|
11 |
Overhead Projector |
2 |
|
12 |
CAM Working Station |
5 |
|
13 |
Panel Sawing Machine |
1 |
|
14 |
Beveling Machine |
1 |
|
15 |
Oven |
8 |
|
16 |
Sawing Machine |
1 |
|
17 |
Etching Machine |
1 |
|
18 |
Solder Remover Machine |
1 |
|
19 |
80HP Air Compressor |
2 |
|
20 |
5 Spindle Drilling Machine |
3 |
|
21 |
6 Spindles Drilling Machine |
13 |
|
22 |
Routing Machine |
2 |
|
23 |
Scoring Machine |
5 |
|
24 |
Automatic Dry Film Presser |
2 |
|
25 |
Baking & Press Machine |
3 |
|
26 |
Flying Probe Tester |
1 |
YUBRIGHT
PCB Q.C. INSTRUMENTS
|
1 |
Auto Feeding Test Machine |
6 |
|
2 |
Open / Short testing Machine |
9 |
|
3 |
500X Magnifier |
1 |
|
4 |
30X Magnifier |
5 |
|
5 |
10X magnifier |
10 |
|
6 |
Micro Section |
1 |
|
7 |
Coating Measurement Instrument |
1 |
|
8 |
X-ray |
1 |
|
9 |
Digital Caliper |
6 |
|
10 |
Reflow tester |
2 |
|
11 |
Pin Gauge |
6 |
|
12 |
Chemical Laboratory |
1 |
|
13 |
Humidity Chamber |
10 |
|
14 |
PH Meter |
5 |
|
15 |
Omega tester |
1 |
|
16 |
Impedance Control tester |
1 |
|
17 |
Vision Aided Measurement Machine |
1 |
